Satellite Communication Converters
Satellite Communication (SATCOM) Converters
Satellite Communication Converters are key elements of any Satcom System. ERZIA presents a selection of highly reliable and performant converters, including solutions for both military and civil bands in the same hardware, extended temperature ranges, tested at high altituteds, optimized power efficiency and noise figures and more. Check our catalog below or contact us for custom solutions.
REQUEST A QUOTE
- Login for price information
- Request a quote
- Contact us for your specific application requirements or any questions
- Download our product guide
Note to our European customers: products are delivered EXW from our facility in Santander, Spain.
Note to our USA customers: products are delivered EXW from our facility in Alexandria, VA.
Block Up Converters (BUC)
Part Number | Type | RF Out (GHz) | Psat (dBm) | Plin (dBm) | IF In (MHz) | Gain (dB) | Download | Price (EUROS) | Get Quote |
|---|---|---|---|---|---|---|---|---|---|
| ERZ-BUC-2750-3100-43 | Ka-Band BUC
| 27.5-31
| 43.00
| 40.00
| 950-1950
| Adjustable 45-75
| - | Get a quote | |
| ERZ-BUC-4775-4825-37 | V-Band BUC
| 47.75-48.25
| 37.00
| 34.00
| 1250-1750
| 50
| - | Get a quote |
Low Noise Block Downconverter (LNB)
| Part Number | Type | RF IN (GHz) | Noise Figure (dB) | Gain (dB) | IF Out (MHz) | Pout max (dBm) | Download | Price (EUROS) | Get Quote |
|---|---|---|---|---|---|---|---|---|---|
| ERZ-LNB-1770-2120-75-1.5 | Ka-Band LNB
| 17.7-21.2
| 1.50
| 55
| 950-1950
| 15.00
| - | Get a quote | |
| ERZ-LNB-3750-4250-50-3 | Q-Band LNB
| 37.5-42.5
| 2.50
| Adjustable 45-75
| 1250-1750
| 12.00
| - | Get a quote |
