ERZ-HPA-3750-4250-39
Q Band Power Amplifier |
37.5–42.5
GHz | 10 W Psat
Description
The ERZ-HPA-3750-4250-39 is a Ka Band High Power Amplifier providing an output power of 38.5 dBm and a gain of 49 dB. The compact size and modularity makes it ideal for a wide range of applications.
Download
Key Features
- Frequency Range (GHz): 37.5-42.5
- Output Power (dBm): 40
- Small Signal Gain (dB): 49
- Noise Figure (dB): 7
- Bias: 24
Specifications
| Frequency Start (GHz): | 37.5 |
| Frequency Stop (GHz): | 42.5 |
| Output Power (dBm): | 40 |
| Gain (dB): | 49 |
| Gain flatness (dB): | ± 5 |
| Noise Figure (dB): | 7 |
| VSWR IN: | 2.0:1 |
| VSWR OUT: | 2.0:1 |
| Power supply (V): | 24 |
| Current (mA): | 4150 |
| Power consumption (W): | 100 |
