ERZ-HPA-0200-0600-43-NS

High Power Amplifiers 2 to 6GHz, Gain 43dB, Psat 43dBm

ERZ-HPA-0200-0600-43-NS High Power Amplifiers 2 to 6GHz, Gain 43dB, Psat 43dBm

Get a quote

Description

The ERZ-HPA-0200-0600-43-NS is a microwave power amplifier based in GaN, specially prepared for New Space applications. It is based on its COTS equivalent, maintaining electrical performance and including key features ideal for new space applications, including radiation tolerance, performance in vacuum and outgassing compatibility, among others.

Download

PDF IconERZ-HPA-0200-0600-43-NS_1

Key Features

  • Frequency Range: 2 to 6 GHz
  • Typical values: Gain 44dB, Psat 43dBm
  • RF connectors (I/O): SMA Female IN/OUT
  • Sub-D for control and DC connection

Specifications

Frequency Start (GHz): 2
Frequency Stop (GHz): 6
Output Power (dBm): 43
Gain (dB): 44
Gain flatness (dB): ±1
VSWR IN: 1.3:1
VSWR OUT: 1.8:1
Power consumption (W): 105
Max. Input DC (no damage) (V): 32

Mechanics and Housing
