ERZ-LNA-2400-4400-23-2.5
Wideband Low Noise Amplifier
Description
Download
Key Features
- Frequency Range (GHz): 24.00-44.00
- Output Power (dBm): 6
- Small Signal Gain (dB): 23
- Noise Figure (dB): 2.5
Specifications
| Frequency Start (GHz): | 24.00 |
| Frequency Stop (GHz): | 44.00 |
| Output Power (dBm): | 6 |
| Gain (dB): | 23.00 |
| Gain flatness (dB): | 1 |
| Noise Figure (dB): | 2.5 |
| Power supply (V): | 12 |
| Current (mA): | 16 |
| Power consumption (W): | 0.2 |
Applications
Ordering Information
