ERZ-LNA-0700-1300-21-1
X Band Low Noise Amplifier
Description
Download
Key Features
- Frequency Range (GHz): 7.00-13.00
- Output Power (dBm): 11
- Small Signal Gain (dB): 24
- Noise Figure (dB): 1.2
Specifications
| Frequency Start (GHz): | 7.00 |
| Frequency Stop (GHz): | 13.00 |
| Output Power (dBm): | 11 |
| Gain (dB): | 24.00 |
| Gain flatness (dB): | 1 |
| Noise Figure (dB): | 1.2 |
| Power supply (V): | 12 |
| Current (mA): | 20 |
| Power consumption (W): | 0.25 |
| Temperature (operation) (°C): | -45 to +85 |
| Temperature (storage) (°C): | -55 to +125 |
Applications
Ordering Information
