ERZ-LNA-3600-4000-29-3.5

Login to see priceGet a quote

Ka Band Low Noise Amplifier

Description:

The ERZ-LNA-3600-4000-29-3.5 is a Low Noise Amplifier that provides a Noise Figure of 3,5 dB with a Gain of 29 dB

Download:
PDF icon ERZ-LNA-3600-4000-29-3.5.pdf
Key Features
Frequency Range (GHz):
36.0 to 40
Output Power (dBm):
10
Small Signal Gain (dB):
29
Noise Figure (dB):
3.5
Bias:
Power supply: 12 V
Package Dimensions:
16x30x17,5 mm
Connectors:
2.92 mm Female
Frequency Start (GHz)
36.0
Frequency Stop (GHz)
40
Output Power (dBm)
10
Gain (dB)
29
Gain flatness (dB)
±1,5
Noise Figure (dB)
3.5
VSWR IN
2.5:1
VSWR OUT
2.5:1
Power supply (V)
12 ±3
Current (mA)
83
Power consumption (W)
0.5
Max. Input DC (no damage) (V)
15
Max. RF input power (dBm)
15
Temperature (operation) (°C)
-45 to 85
Temperature (storage) (°C)
-55 to 125
Applications:

Industrial / Laboratory
Satcom / Telecom
Space / Aerospace / Military

Outline Drawing:
Ordering Information:
